Plan Plus Compact
Myson Plan Plus Compact radiators provide refined heating
- Refined finish
- Optimal heat distribution
- Decorative grille & side panels
- Suitable for low temperature systems
- Child-proof attachment
Product description
The Myson Plan range offers a contemporary alternative to the traditional panel radiator with its minimalist feel, good looks and leading performance. Myson Plan Plus Compact has a decorative front panel and features side panels and top grille. Type 11, Type 21 and Type 22 profiles are available, with Type 21 & 22 also available as vertical models.
Technical Specifications
| ETIM Class | EC011022 - Panel radiator |
|---|---|
| Material | Steel |
| Type | 11 - 21 - 22 |
| Surface structure front side panel | Flat smooth |
| Water-bearing front panel | Yes / No |
| Suitable for damp space | No |
| Height [mm] | 300 - 600 |
| Length [mm] | 400 - 3000 |
| Depth [mm] | 62 - 104 |
| Heat emission according to EN 442 20 °C - 55/45 [W] | 1.02 - 998 |
| Heat emission according to EN 442 20 °C - 75/65 [W] | 1.006 - 988 |
| Heat emission according to EN 442 20 °C - 70/40 [W] | 0 - 1451 |
| Heat emission according to EN 442 laboratory | Yes |
| N-exponent | 1.282 - 1.3295 |
| Max. operating pressure [bar] | 0.01 |
| Water content [l] | 1 - 18 |
| Standard colour | Yes |
| Colour | White |
| RAL-number | 9016 |
| Degree of gloss | Glossy |
| Welded-on strips | Yes |
| With side lining | Yes |
| With top cladding | Yes |
| Collapsible | No / Yes |
| Number of standard connections | 4 |
| Connection 2, left side low | Outlet flow - Inlet/outlet flow |
| Connection 3, left side top | Inlet flow |
| Connection 6, right side top | Inlet flow |
| Connection 7, right side low | Inlet/outlet flow - Outlet flow |
| Thread size (inch) | 1/2 inch |
| Thread connection | Internal thread |
| With connection block | No |
| With single-point connection | No |
| With de-aeration connection | Yes |
| With de-aerator | Yes |
| With drain possibility (connection) | Yes |
| With drain valve | No |
| With integrated thermostatic valve | No |
| With thermostat button | No |
| With wall brackets | Yes |
| Suitable for electrical element | No |
| With electrical element | No |
| With blind stops | No |
| With mounting material | Yes |
| Suitable for towel holder | No |
| With towel holder | No |
| Recessed towel holder | No |
| Suitable for shelf | No |
| Watt Per Meter [W/m] | 529 - 1676 |
| Factor K | 1.802 - 27.709 |
| Heat emission according to EN 442 20 °C - 45/30 [W] | 97 - 596 |
| Heat emission according to EN 442 20 °C - 45/35 [W] | 123 - 750 |
| Heat emission according to EN 442 20 °C - 50/30 [W] | 112 - 683 |
| Heat emission according to EN 442 20 °C - 55/30 [W] | 126 - 769 |
| Heat emission according to EN 442 20 °C - 55/35 [W] | 156 - 954 |
| Heat emission according to EN 442 20 °C - 60/30 [W] | 139 - 853 |
| Heat emission according to EN 442 20 °C - 60/40 [W] | 202 - 1234 |
| Heat emission according to EN 442 20 °C - 60/45 [W] | 229 - 1404 |
| Heat emission according to EN 442 20 °C - 65/45 [W] | 249 - 1525 |
| Heat emission according to EN 442 20 °C - 70/55 [W] | 331 - 2028 |
| Heat emission according to EN 442 20 °C - 80/60 [W] | 401 - 2456 |
| Heat emission according to EN 442 20 °C - 90/70 [W] | 515 - 3157 |
| Heat emission according to EN 442 20 °C – 55/45 [Btu/h] | 481 - 8697 |
| Heat emission according to EN 442 20 °C – 75/65 [Btu/h] | 928 - 17156 |
| Heat emission according to EN 442 21 °C - 45/35 [W] | 114 - 700 |
| Heat emission according to EN 442 21 °C - 55/45 [W] | 203 - 1242 |
| Heat emission according to EN 442 21 °C - 60/40 [W] | 192 - 1177 |
| Heat emission according to EN 442 21 °C - 75/65 [W] | 398 - 2435 |
| Heat emission according to EN 442 24 °C - 45/30 [W] | 65 - 399 |
| Heat emission according to EN 442 24 °C - 45/35 [W] | 91 - 554 |
| Heat emission according to EN 442 24 °C - 50/30 [W] | 77 - 472 |
| Heat emission according to EN 442 24 °C - 55/45 [W] | 174 - 1063 |
| Heat emission according to EN 442 24 °C - 60/40 [W] | 165 - 1009 |
| Heat emission according to EN 442 24 °C - 60/45 [W] | 192 - 1178 |
| Max. Operating Temperature [°C] | 110 |
| Mounting Direction | Horizontal |
| Number of wall brackets | 2 - 3 |
| Number of floor brackets | 0 - 2 |
| CO2/Kg equivalent per kg of material | 2.8 |
| CO2/Kg equivalent per KW of heat delivered by the articles | 54.66 |
| Weight [kg] | 1.115 - 108.711 |
