Manifold Control SystemsUK
- Efficient DistributionGB
- Customizable ZonesGB
- Modular DesignGB
- CompatibilityGB
- Smart IntegrationUK
Product description
Modular manifold systems equipped with advanced flow meters, valves, and control mechanisms to regulate the distribution of heated water throughout the underfloor heating network. These systems ensure precise temperature control and efficient operation of the heating systemUK
Technical Specifications
| ETIM Class | EC011022 - Panel radiator |
|---|---|
| Material | Stainless steel |
| Type | 11 - 22 - 33 |
| Surface structure front side panel | Profiled |
| Water-bearing front panel | Yes |
| Suitable for damp space | Yes |
| Height [mm] | 1800 |
| Length [mm] | 400 - 800 |
| Depth [mm] | 40 - 70 |
| Heat emission according to EN 442 20 °C - 55/45 [W] | 711 - 900 |
| Heat emission according to EN 442 20 °C - 75/65 [W] | 501 - 850 |
| Heat emission according to EN 442 20 °C - 70/40 [W] | 201 - 851 |
| Heat emission according to EN 442 laboratory | Yes |
| N-exponent | 1.3 |
| Max. operating pressure [bar] | 10 |
| Water content [l] | 3 - 7 |
| Standard colour | Yes |
| Colour | White |
| RAL-number | 9016 |
| Degree of gloss | Glossy |
| Welded-on strips | No |
| With side lining | No |
| With top cladding | No |
| Collapsible | No |
| Number of standard connections | 4 |
| Connection 1, bottom left | Inlet flow |
| Connection 2, left side low | Inlet flow |
| Connection 6, right side top | Outlet flow |
| Connection 7, right side low | Outlet flow |
| Thread size (inch) | 1/2 inch |
| Thread connection | Internal thread |
| Connection combi 88, underside right/underside right | No |
| With single-point connection | Yes |
| With de-aeration connection | Yes |
| With de-aerator | Yes |
| With drain possibility (connection) | Yes |
| With drain valve | No |
| With integrated thermostatic valve | No |
| With wall brackets | Yes |
| Suitable for electrical element | No |
| With electrical element | No |
| With blind stops | No |
| With mounting material | Yes |
| With towel holder | No |
| Recessed towel holder | No |
| Factor K | 4.6 - 7.9 |
| Max. Operating Temperature [°C] | 110 |
| Mounting Direction | Horizontal |
| Number of wall brackets | 0 |
| Number of floor brackets | 2 |
| Weight [kg] | 5 - 8 |
