Product description
Zabrania się opróżniania całej instalacji lub jej części z wody i pozostawiania w tym stanie. Dotyczy to również nowych instalacji poddanych próbom szczelności. W razie potrzeby opróżnienia instalacji np. z powodu remontu lub konserwacji, wodę należy usunąć tylko z tej części instalacji, z której jest to niezbędne. Po wykonaniu prac opróżnioną instalację należy natychmiast ponownie napełnić wodą. Ilość wody zużywanej do napełniania i uzupełniania instalacji centralnego ogrzewania należy kontrolować np. przy pomocy wodomierza.
Technical Specifications
| ETIM Class | EC011023 - Tube radiator |
|---|---|
| Material | Steel - Stainless steel - Copper - Cast iron - Aluminium |
| Material quality | Other - Rustproof and acidproof steel |
| Number of tubes | 15 - 58 |
| Height [mm] | 714 - 1809 |
| Length [mm] | 400 - 900 |
| Depth [mm] | 50 - 54 |
| Shape of radiation tube | Round - Rectangular - Square - Oval - Triangular |
| Shape of collector | Round - Rectangular - Square - Oval - D profile |
| Installation | Horizontal - Vertical |
| Radiant tube | Vertical - Horizontal |
| Radiator design | Straight - Round - Quarter round - Half round - Slightly bent |
| Towel radiator model | No / Yes |
| Heat emission according to EN 442 20 °C - 55/45 [W] | 15 - 100 |
| Heat emission according to EN 442 20 °C - 75/65 [W] | 30 - 200 |
| Heat emission according to EN 442 20 °C - 70/40 [W] | 22.5 - 150 |
| N-exponent | 1.1584 - 1.2659 |
| Max. operating pressure [bar] | 6 - 10 |
| Water content [l] | 2.65 - 5.21 |
| With fan heater | No |
| Max. input power heating [W] | 300 - 700 |
| Standard colour | Yes |
| Colour | Beige |
| RAL-number | 9016 |
| Degree of gloss | Glossy - Matt |
| Surface protection | Lacquered |
| Suitable for damp space | No |
| With towel holder | Yes |
| With mirror | No |
| Mounting method | Perpendicular to wall |
| With side lining | Yes |
| With top cladding | No |
| Swivelling | Yes |
| Applicable with hot tap water circuit | Yes |
| Number of standard connections | 4 |
| Connection 1, bottom left | Inlet/outlet flow |
| Connection 2, left side low | Double connection, outlet-inlet |
| Connection 3, left side top | Other |
| Connection 4, top left | Other |
| Connection TC, top center | Other |
| Connection 5, top right | Double connection, outlet-inlet |
| Connection 6, right side top | Other |
| Connection 7, right side low | Double connection, outlet-inlet |
| Connection 8, bottom right | Other |
| Connection BC, bottom center | Double connection, outlet-inlet |
| Thread size (inch) | 1/2 inch |
| With single-point connection | No |
| Thread connection | External thread |
| With de-aeration connection | No |
| With de-aerator | No |
| With drain possibility (connection) | No |
| With drain valve | No |
| With integrated thermostatic valve | No |
| With consoles | No |
| Suitable for electrical element | No |
| With blind stops | No |
| With mounting material | No |
| Certified according to NF (hot water) | No |
| Factor K | 5 |
| Max. Operating Temperature [°C] | 110 |
| Variant | 4 |
| Mounting Direction | Vertical |
| Number of wall brackets | 5 |
| Number of floor brackets | 4 |
| Weight [kg] | 4 |
