Discover comfort and efficiency with EcoTech Elite.
- Ensures yearround comfort with precision control
- Energyefficient, cuts utility costs significantly.
- Purifies air, promotes healthier indoor environments
- Smart connectivity for remote monitoring and control.
- Durable, low maintenance for longterm reliability.
Product description
Innovative HVAC solution for superior comfort and efficiency.
Technical Specifications
| ETIM Class | EC011022 - Panel radiator |
|---|---|
| Material | Steel - Stainless steel |
| Type | 32 - 21 - 33 - 44 |
| Surface structure front side panel | Flat profiled |
| Water-bearing front panel | Yes |
| Suitable for damp space | Yes |
| Height [mm] | 120 - 150 |
| Length [mm] | 210 - 245 |
| Depth [mm] | 15 - 52 |
| Heat emission according to EN 442 20 °C - 55/45 [W] | 1254 - 1980 |
| Heat emission according to EN 442 20 °C - 75/65 [W] | 1279 - 2005 |
| Heat emission according to EN 442 20 °C - 70/40 [W] | 1272 - 1998 |
| Heat emission according to EN 442 laboratory | Yes / No |
| N-exponent | 1.0002 - 1.87852 |
| Max. operating pressure [bar] | 10 - 15 |
| Water content [l] | 15 - 56 |
| Standard colour | No / Yes |
| Colour | Grey - Black - Gold |
| RAL-number | 1004 - 9005 |
| Degree of gloss | Glossy |
| Welded-on strips | Yes / No |
| With side lining | No / Yes |
| With top cladding | No / Yes |
| Collapsible | Yes / No |
| Number of standard connections | 2 - 7 |
| Connection 1, bottom left | Inlet/outlet flow - Double connection, inlet-outlet - Double connection, outlet-inlet |
| Connection combi 11, underside left/underside left | Yes |
| Connection 2, left side low | Double connection, outlet-inlet - Double connection, inlet-outlet - Outlet flow - Other |
| Connection 3, left side top | Control valve - Inlet/outlet flow - Outlet flow |
| Connection 4, top left | Double connection, inlet-outlet - Double connection, outlet-inlet - Inlet flow - Outlet flow |
| Connection TC, top center | Other - Double connection, inlet-outlet |
| Connection 5, top right | Outlet flow - Inlet flow - Inlet/outlet flow - Double connection, outlet-inlet |
| Connection 6, right side top | Outlet flow |
| Thread size (inch) | 1/2 inch - 3/4 inch |
| Thread connection | Internal thread/external thread - Internal thread - External thread |
| Connection combi 88, underside right/underside right | Yes |
| With single-point connection | No / Yes |
| With de-aeration connection | Yes / No |
| With de-aerator | Yes / No |
| With drain possibility (connection) | No / Yes |
| With drain valve | Yes / No |
| With integrated thermostatic valve | No / Yes |
| With wall brackets | No / Yes |
| Suitable for electrical element | No |
| With electrical element | No |
| With blind stops | No |
| With mounting material | No |
| With towel holder | No |
| Recessed towel holder | No |
| Factor K | 1000 - 1586 |
| Max. Operating Temperature [°C] | 100 - 125 |
| Mounting Direction | Vertical - Horizontal |
| Number of wall brackets | 4 - 6 |
| Number of floor brackets | 2 - 6 |
| Weight [kg] | 25 - 35 |
